P3 - Diaphragm Pump

P3 - Diaphragm Pump

Regular price
Regular price Sale price
Sale Sold out
Shipping calculated at checkout.

P3 - Diaphragm Pump

  • Fluid connections: 1/4” BSP
  • Air connection: 4 mm
  • Max flow-rate: 4 lt/min
  • Max air pressure: 6 bar
  • Max delivery head: 60 m
  • Max Suction Lift Dry: 3 m


  • Max Suction Lift Wet: 9,8 m
  • Max Solid passing: 2 mm
  • Noise level: 62 dB
  • Max Viscosity: 5.000 cps
  • Displacement per Stroke: 18 CC~
