Norbar - Electronic Torque Tools - EvoTorque 2

The EvoTorque®2 is an electronic torque tool designed to accurately apply torque to threaded fasteners. Tools are factory calibrated to ±3% of reading.
The unique ‘intelligent joint sensing’ technology continually measures the joint during tightening and when necessary, employs dynamic braking to
avoid torque over-shoot due to motor inertia. Consequently, EvoTorque®2 can apply torque accurately over a wide range of joint rates from hard (high
torque rate) through to soft (low torque rate). All EvoTorque®2 tools are highly tolerant of supply voltage and frequency variation. If the supply voltage
is outside of tolerance then, as a safety feature, the tool will be prevented from starting.
The EvoTorque®2 has the ability to memorise multiple targets, work IDs, user IDs and readings. A work sequence (flow) can be performed on the
EvoTorque®2, taking the user through a pre-defined tightening sequence. The tool has four modes of operation: Torque, Torque & Angle, Torque & Angle
with Final Torque and Torque Audit. The unique Audit Mode is a sophisticated feature for testing pre-tightened bolts with minimal impact on the original
fastening torque and can provide quality control data for monitoring joint performance over time. EvoTorque®2 builds on the original tool with these
additional features:

• Multiple units of torque measurement, N·m, lbf·ft, ft·lb and kgf·m
• Calibrated from 20% to 100% of tool range
• Torque, Torque & Angle and Torque Audit modes available
• In Torque & Angle Mode and Audit Mode, torque can be set from
10% of tool maximum
• Display and on-board storage of final torque or torque and angle
values
• Memory capacity for 3,000 readings, time and date stamped
• Clear indication of successful joint application
• USB and Bluetooth® 4.0 data transfer (also called Bluetooth® Smart)
• Complimentary PC software ‘EvoLog’ for data management and tool
configuration
• 12 user IDs can be downloaded to the tool and results can be stored
against individual users
• 20 unique stand-alone targets plus 20 unique work group targets for
each work group

• Results can be output in CSV (comma-separated values) format for
users not able to use EvoLog
• Ability to produce and store real time graphs via EvoLog
• Torque & Angle with Final Torque
• ‘Usage’ counter gives the ability to see the amount of times the tool
has been used since the last reset
• 'Operation Direction' feature designed primarily for undoing bolts.
When doing sequence tightening, it is now possible to undo an
incorrectly tightened bolt without interrupting the sequence
• Two stage tightening gives faster application of a Snug Torque &
Angle Target
• 'Turn Angle' option can be used to check if bolts have already been
tightened in an assembly process
• Tool can be integrated into third party control systems
• Two different lock levels, lock level 1 as per previous lock, lock level
2 will not allow user to exit the run screen or change the target
• Maximum Audit Mode target angle of 720°

EvoTorque®2's intelligent joint sensing technology always detects
which type of bolt you are working with.

*High torque rate and low torque rate as defined by ISO 5393 'Rotary tools
for threaded fasteners - Performance test method'
EvoTorque®2's intelligent joint sensing technology always detects
which type of bolt you are working with.
The EvoTorque®2 has been designed to complete joints of 30° and
above to within the tools ±3% accuracy. For joints below 30° use the
tools audit mode feature.

Traditional electronic torque tools give vastly different results depending on the joint type. Norbar’s 'intelligent joint sensing' technology eliminates
these issues so that you can be confident in your bolting work.
